wattson shows how much electricity you are using in your home, school or office

FEATURES

Simple to set up.

• 1-2-3 easy clip installation
• Real-time energy usageSimple to use.

• Easy legible display
• Instant feedback
• View in numbers & colours Simple to save money.

• Captures energy usage
• View Historical data
• Decisions based on facts

Tech Specs

· Able to measure single, twin and three phase systems (extra clips required).
· 12.5KW max per phase, 37.5kW for 3-phase installation.
· 1W resolution of display.
· 14 – segment LED digital display.
· RGB LED full colour ambient light. · 256kb non-volatile EEPROM internal memory
· 433.92Mhz transmitter / receiver, approx. 30m range.
· Max radiated power 2.26mW
· 3 – 20 second refresh rate, user changeable.
· 3 – 6 month battery life (Sensor).
· 5-3 hour battery life (Display).
· USB 1.0 compatible.
· USB-A to USB mini-A cable supplied.
· Currency changeable: £. $, €, R, P, k, F.
· Casings made from Polycarbonate, Polyvinyl and ABS.
· Display: 105mm X 170mm x 55mm.
· Transmitter: 110mm x 84 mm x 26 mm.
· Software Mac & PC compatible.
· Packaged weight 1kg.

INFO

• 1- 3 phase power compatible for home and small offices, additional 50Amp sensor clips required.

• When you purchase wattson 01 you will be provided with a single 50Amp sensor clip. Most houses in Hong Kong use single phase electricity and only require one clip to measure. Some premises may have three phase electricity, this is normal for houses with larger electricity loads and most businesses. To measure three phase electricity you will need to purchase 2 additional 50Amp sensor clips, available from our us.

• Supplied with a single power unit for the display (UK or EU available). The transmitter unit is powered by 4xAA battery (supplied) or DC Power (requires additional DC power unit available in the web-shop)

• Software included with product to view chronological & real time data, compatible with PC operating systems Windows XP (with SP1 and SP2) and Windows Vista and Apple MAC operating system 10.4 or higher

       Materials & Dimensions
       Plastic. 170 w x 104 d x 56 h mm
